Mini GBIC / SFP Single-mode Fibre Adapter (SMF)
SKU: SFPSM1
Available Now
$68.18
The SFPSM1 is a compact, hot-pluggable SFP module for linking high speed optical fibre infrastructure to a network. Easily configure and upgrade networks for high-speed networking over optical fibre, with a bit rate of up to 1.25Gbps.
Product features:
Installed in the 1000 Base-X (Combo port) SFP ports of VIP Vision PoE switches.
- Mini GBIC / SFP optical fibre adapter
- Transfer data over optical fibre at up to 1.25Gbps
- SFP (Small Form-factor Pluggable)
- Compatible with SMF (single mode fibre)
- 1310nm VCSEL laser transmitter
- Hot-pluggable, allowing for installation and removal while the system is running
- Built-in digital diagnostic functions, including optical power monitoring
Details
| Manufacturer | VIP Vision |
|---|---|
| Supplier | RhinoCo.com.au |
| Weight | 0.03 |
| Dimensions | 0.059(W)x0.012(H)x0.012(D)m |
| Warranty | 1 |
| Category | Networking and Communication > Network Switches > Switch Accessories |
Specs
| Cable Type | Single-mode Fibre |
|---|---|
| DOM Support | Yes |
| Form Type | SFP (Small Form-factor Pluggable) |
| Interface | LC duplex |
| Max Bit Rate | 1.25Gb/s |
| Max Cable Distance | 10km |
| Operating Environment | -40 to 85°C / RH95% (max) |
| Power Supply | 3.3VDC / 300mA |
| Protocols | SFF-8472 MSA Compliant, IEEE 802.3ah-2004, ANSI Fibre Channel |
| Receiver Sensitivity | < -21dBm |
| TX Power | -9.5 ~ -3dBm |
| Wavelength | 1310nm |
